High Strength Hex Bolt for Steel Structure

Call Us
18003305116

18003305116
Add Us Wechat

产品编号 LS01
Product Description
ApplicationSteel structural bolts are mainly used in steel structural engineering to connect the connection points of steel structural steel plates.
ShapeMulti-form customization
ModelUniversal Thread/Self-designed Thread



Product Parameters

Product Name

High Strength Hex. Bolt for Steel Structure

Specification

M16M20M22M24M27M30

Shape

The large hexagonal steel structural bolt consists of one bolt, one nut, and two washers.

Torsional shear steel structural bolts consist of one bolt, one nut, and one washer

Grade

10.912.9

Material

35CRMO,45#Steel.

Coating

Electrogalvanizing, hot-dip galvanizing, oxidation blackening, Black Oxide, DACROMAT

Advantage

1. Strong adaptability to geometric shapes; Simple construction; Without weakening the cross-section, automated operation can be achieved; The connection has good airtightness and high structural stiffness.

2. Reliable force transmission, good toughness and plasticity, easy quality inspection, and good resistance to dynamic loads.

3. Convenient loading and unloading, simple equipment.

4. Friction type shear deformation is small, with good elastic performance, especially suitable for structures under dynamic loads. The bearing capacity of the pressure bearing type is higher than that of the friction type, and the connection is compact.

Quality Control

DIN standard,100% Whole range inspection through the production.

Certificate

DIN6914+DIN6915+DIN6916

Application on

Steel structural bolts are mainly used in steel structural engineering to connect the connection points of steel structural steel plates.

After-sales Service

Provide permanent after-sales service.
